Mercedes Benz W220 2203202438 Front Air Suspension Kit

Mercedes Benz W220 2203202438 Front Air Suspension Kit

  • Mercedes Benz W220 2203202438 Front Air Suspension Kit
  • Mercedes Benz W220 2203202438 Front Air Suspension Kit
  • Mercedes Benz W220 2203202438 Front Air Suspension Kit
  • Mercedes Benz W220 2203202438 Front Air Suspension Kit
Mercedes Benz W220 2203202438 Front Air Suspension Kit
Product Details:
Place of Origin: China
Brand Name: GZ Bravo
Certification: ISO 9001:2015
Model Number: 2203202438 2203205113
Payment & Shipping Terms:
Minimum Order Quantity: 20
Packaging Details: 100 pieces in one carton box
Delivery Time: 3-15days
Payment Terms: T/T, Western Union,Credit Card, Ali Pay, Word First,etc.
Supply Ability: 10000 Pieces/Months
Contact Now
Detailed Product Description
Item: Air Suspension Sleeve OEM No.: 2203202438 2203205113
Material: Natural Rubber, Chloroprene Rubber,Cord Fabrics Vehicle For: Mercedes-Benz S Class W220
Layers: 4 Layers Length: 145 MM
Thickness: 2.0 MM A-OD: 125
B-OD: 92 Function: Fix Air Suspension Spring
High Light:

Benz W220 front air suspension kit

,

2203202438 front air suspension kit

,

2203202438



Rubber Sleeve for Mercedes-Benz W220 Front Air Suspension Repair Kits Air Rubber Sleeve Air Bellow 2203202438





PRODUCT DESCRIPTION



GZ Bravo's Air Suspension Rubber Sleeves mostly consists of 4 layers, one layer inner rubber, two layers cord fabrics and one outer rubber. The rubber use the imported Malaysia natural rubber and Chloroprene rubber. And the cord fabrics use the famous "Shenma" brand. Because of the strict raw material control and advanced technology, so our rubber sleeves can meet the same performance standard as Germany-made original rubber bellows. Only good rubber sleeve can support air suspension spring or air suspension shock long life.



Item Air Suspension Sleeve
Vehicle For Mercedes-Benz S Class S280 S320 S350 S400 S430 S450 S500 S600
OEM Numbers 2203202438 2203205113
Material Natural Rubber, Chloroprene rubber,Cord Fabrics
A-End-Diameter 125 MM
B-End-Diameter 92 MM
Length 145 MM
Thickness 2.0 MM
Layers 4 Layers
Hardness Soft, High quality





PRODUCT FIT FOR



Mercedes-Benz



S Class(W220)1998/10-2005/06 Front



S280

S320

S350

S400

S430

S480

S500

S600





REFERENCE OE/OEM NUMBER



2203202438

2203205113

2203208213

2203202238



Mercedes Benz W220 2203202438 Front Air Suspension Kit 0

Mercedes Benz W220 2203202438 Front Air Suspension Kit 1





GZ BRAVO AIR SUSPENSION RUBBER SLEEVE MAIN CATALOGUE



NO. Car Brand Car Model Position Length (MM) SIZE ( Units MM)
Thickness (MM) A-Outside Diameter B Outside diameter
A-OD B-OD
1 Mercedes-Benz W164/W251 Front 340 3.00 133 101
2 Mercedes-Benz W164/W251 Rear 360 3.00 137 106
3 Mercedes-Benz W220 Front 145 2.00 125 92
4 Mercedes-Benz W220 Rear 300 2.00 101 88
5 Mercedes-Benz W221 Front 145 2.00 128 96
6 Mercedes-Benz W221 Rear 155 2.00 132 96
7 Mercedes-Benz W211 Front 210 3.00 126 85
8 AUDI A6C5 Front 355 3.00 122 98
9 AUDI A6C5 Rear 400 3.00 105 95
10 AUDI A6C6 Front 190 2.50 124 88
11 AUDI Q7/Cayenne Front 260 3.00 144 94
12 AUDI Q7/Cayenne Rear 270 3.00 132 84
13 AUDI A8D3 Front 230 2.50 126 85
14 AUDI A8D3/Panamera Rear 230 3.00 122 96
15 AUDI A8D4 Front 190 2.50 126 88
16 AUDI A8D4 Rear 230 3.20 126 96
17 BMW E66 Rear 300 2.00 101 88
18 BMW E70 Rear 345 3.20 102 98
19 BMW E53 Front 310 3.00 140 96
20 BMW E53 Rear 340 3.00 128 80
21 BMW E39 Rear 287 3.00 127 80
22 BMW GT/E61 Rear 350 3.00 80 80
23 BMW F02/Phaeton Front Rear 200 2.50 128 93
24 Land Rover L322  Front 400 3.20 167 101
25 Land Rover Discover 3/Sport Front 340 3.00 122 96
26 Land Rover Discover 3/Sport Rear 310 2.80 162 96
27 Porsche Panamera Front 230 3.00 132 84.00
28 Jaguar XJ60,XJ70 Front 225 2.00 101 91
29 Jaguar XJ60,XJ70 Rear 225 2.00 101 91
